Annilte Adjustable link v belt power twist plus drive Link V Belt

Power twist is individual links made of high performance polyurethane/polyester composite material. Links are connected andsecured together by hand using a twist-lock design.

Type:V-BELT

Material:PU

Send email to us WhatsApp Send Inquiry

Product Detail

Product Tags

Power twist is individual links made of high performance polyurethane/polyester composite material. Links are connected andsecured together by hand using a twist-lock design.

Model	Size	Color	Material	Working temperature
Z10	8.5mm-11.5mm	Red	PU	-10~80℃
A13	11.5mm-14.5mm	Red
B17	15.5mm-18.5mm	Orange with nuts
C22	20.5mm-23.5mm	Orange with nuts

Our Advantages

Longer Belt Life in Harsh Operating Conditions

Our link belt adopts high performance polyurethane and polyester composite materials which guarantee excellent durability in harsh
conditions. They will outperform conventional rubber V belts in handling hostile environments, including exposure to oil, grease,
water and so on. They are also more resistant to abrasion and will operate, with no loss in performance, at a more extreme
temperature range from -40°C to 90°C.

Reduced Belt Stock…Any Belt, Any Time

There’s no need to maintain inventory of numerous different endless V belts to cover all your drives. Carry a box in stock of each

common size and you’re almost 100% covered with a significant reduction in working capital tied up in spares.

Easier and Faster Installation

Unique “quick connect” belt designs provide for easier and faster belt installation, even on captured or restricted access drives

— no tools required. Belts are easily made up to the required length, by hand, in seconds and can be rolled onto a drive just like
a bicycle chain. No need to dismantle drive components or change existing pulleys.

Minimized Maintenance Time

Power twist drive belt has no need to re-tension. All other power transmission belts, require re-tensioning after an initial “run

in” period. But power twist drive has eliminated that step by pre-seating the tabs on the belt, therefore once you install the
belt properly PT Drive is a Fit it and Forget It option.

Reduced Drive Vibration & System Noise

Link belt do not have the continuous tension cords found in conventional endless belts. As a result, transmitted vibration in the
drive system can be reduced by 50% or more. Consequently, system noise is reduced and, as a bonus, bearing life extended.
