Annilte Anti-skid Treadmill Belt Diamond Pattern Low Noise Home use treadmill running belt treadmill walk belt

Health and environmental protection

1: The surface of the belt is a layer of black PVC plastic [high strength wear-resistant material].

2: The next layer is polyester fiber [can improve the adhesion of the material].

3: The next layer is white PVC material [can reduce the friction between the belt and the plate].

4: The next layer is cotton and fiber composite [anti-static].

Total thickness 1.6/2.0/2.5/3.2mm
Coating thickness  0.9mm
Coating hardness  65ShoreA

Product Detail

Product Tags

We have many years of experience in the conveyor belt industry, but the running belt is different from the industrial conveyor belt,There are higher requirements for underside fabric, surface pattern, noise and connection technology. .For this reason, we have invested a lot of resources to study the factors that affect running belt, which has been completed at present the production technique of grip belt.



Name Treadmill Belt
Fabric layers 4
Pattern  grass/diamond/golf
Total thickness 1.6/2.0/2.5/3.2mm
Coating thickness  0.9mm
Coating hardness  65ShoreA
Total weight  about 2.1Kg/m2
Constant elongation strength  8N/mm
Roller diameter  about 40mm
Operating temperature  -15/+60°C
Max width  2000mm



Features:

1. The qualified use record of 68 million treadmill belts of Annilte, please rest assured to use;

2, the surface of the fine grain composite material, improve the friction coefficient by 30%;

3, the back of the treadmill belt with new fiber material cloth layer, effectively improve the use of time, effectively reduce 60% noise;

4, the use of A+ grade raw materials, smooth running, no deviation, no slag, perfect with the treadmill;

5, seamless, smooth and firm, no deformation, comfortable and durable;

6, multi-color, multi-specification, can be deeply customized.

7, The use of electrostatic conductive wire, improve the conductivity of the running belt, Protect the safety of users, prolong the life of the belt.
