Annilte Wear-Resistant PVC pattern Rough Top conveyor Belting Manufacturer
Grass pattern conveyor belt is a patterned conveyor belt upgraded from pvc conveyor belt. The climbing angle of grass pattern pvc conveyor belt is large, the current one can reach 45 degrees, but there are requirements in the production of climbing conveyor belt, after all, there is a slope will easily cause items to slip off, if the climbing requirement is very high, you can add spacers and retaining edges on the basis of grass pattern.
Grass pattern conveyor belt features: Usually, most of the materials transported for climbing are bulk materials and packaging items. The specifications of grass pattern conveyor belt can be customized according to the customer’s needs, according to the conveying equipment, the size of the appropriate equipment. The main purpose of using grass pattern conveyor belt in most factories is to save floor space and also to save equipment investment and land construction cost, which is one of the reasons why grass pattern conveyor belt is becoming more and more popular.
Lawn pattern conveyor belt is tooth joint method joint based, using high temperature vulcanization to ensure the flatness of the interface and the sturdiness of the joint, no crease, no knife mark. We can choose lap joint, steel buckle or field joint according to customer’s demand.
Lawn pattern conveyor belt is suitable for food industry, logistics industry, woodworking industry, grain industry, tobacco industry, etc.
|
Conveyor Belt
|
||
|
Top Cover
|
Material
|
PVC/PU /Silicone / Rubber
|
|
Color
|
Green/White/Black or custom
|
|
|
Thickness
|
1-10 mm or custom
|
|
|
Hardness
|
65 °shA
|
|
|
Working Temperature
|
-10/+80 ºC
|
|
|
Pattern
|
Grass pattern or custom
|
|
|
Weight
|
4.2 kg/m2
|
|
|
Breaking Load
|
≥100 N/mm
|
|
|
Working Load at 1% Elongation
|
≥9 N/mm
|
|
Annilte is a conveyor belt manufacturer with 15 years of experience in China and an enterprise ISO quality certification. We are also an international SGS-certified gold product manufacturer.
We offer a wide range of customizable belt solutions under our own brand, “ANNILTE.”
Should you require further information regarding our conveyor belts, please do not hesitate to contact us.
