1. Make a simple support frame for recycling the old belt above the new belt in front of the conveyor head, install the traction device on the conveyor head, disconnect the old belt from the conveyor head when changing the belt, connect one end of the old and new belt, connect the other end of the old belt with the traction device, complete the new belt laying and pulling out the old belt through the traction device, and finally complete the connection of the new belt.
2. A simple support frame for recycling old belt is made and set up on the new conveyor belt after the tail roller, and the traction device is installed at a certain distance from the conveyor tail to the roller. When changing the belt, disconnect the old belt from the tail of the conveyor, connect one end of the new belt with one end of the old belt, connect the other end of the old belt with the traction device, and complete the new belt laying and pulling out of the old belt through the traction device. Finally complete the connection of the new tape.
3. Make and install a set of simple guide Angle device on the middle frame of the conveyor, install the traction device at a certain distance from the tail to the roller, disconnect the old belt from the tail when changing the belt, connect one end of the old belt with the traction device and pull out from under the conveyor, and connect the new belt with a lead when the other end of the old belt is pulled to the simple guide Angle device. The new belt is laid and the old belt is pulled out by the traction device, and finally the new belt is connected.
4. Install the traction device in the middle section of the conveyor, install a set of simple guide Angle device in the middle frame of entering the new belt and leaving the old belt, disconnect the old belt from the middle frame belt of the conveyor (or lower belt) when changing the belt, and then connect one end of the old belt with the traction device, and complete the new belt laying belt and pulling out the old belt through the traction device, and finally complete the connection of the new conveyor belt.
