The fundamental reason why a PVC conveyor belt can run off is that the combined force of the external forces on the belt in the direction of the belt width is not zero or the tensile stress perpendicular to the belt width is not uniform. So, what is the method to adjust the PVC conveyor belt to run out? Here are the methods compiled by pvc conveyor belt manufacturers. Hope it can help you
1、Adjustment on the side of the rollers: When the range of the conveyor belt runout is not large, the rollers can be adjusted and installed at the conveyor belt runout.
2、Appropriate tensioning and adjustment of deviation: When the belt deviation is left and right, we should clarify the direction of deviation and adjust the direction of deviation, and we can adjust the tensioning installation appropriately to eliminate the deviation.
3、Single-side vertical roller runout adjustment: The walking belt has been running sideways. Multiple vertical rollers can be installed in the range to reset the rubber belt.
4、Adjust the roller to adjust the runout: The conveyor belt is run out at the roller, check whether the roller is abnormal or moving, and adjust the roller to the degree of normal rotation to eliminate the runout.
5、Adjust the recommended joint runout, PVC conveyor belt runout in the same direction, and large runout at the joint, you can correct the walking belt joint and walking belt centerline to eliminate the runout.
6、Adjust the runout of the bracket: the direction and position of the walking belt are fixed, and the runout is serious. The angle and verticality of the bracket can be adjusted to eliminate runout.
PVC conveyor belt runout is caused by uneven force, so try to keep the items in the middle position of the belt when transmitting items to avoid runout failure.
