Annilte Yellow Green Nylon Flat Belt High Speed Polyamide Transmission belt

Nylon polyamide power drive belt structure of NBR + polyamide + NBR three layers.
It has the characteristics of light weight, high strength, small corrosion, oil resistance, wear resistance, energy saving and so on.
Belt color can be customized, the general color is green/yellow, light green/yellow, green/black, light green/green, etc.

Application Spinning,textile industry
Surface structure wear resistance
Temperature -20 ° C to 80° C
Feature anti-static

Product Detail

Product Tags

Nylon sheet base band is a very widely used in the industrial belt of a plane transmission belt category, nylon sheet base band is nylon sheet as the tension layer and the surface is covered with rubber, cowhide, fiber cloth plane transmission belt (also known as flat belt), has: strong tension, flexural resistance, high efficiency, low noise, fatigue resistance, good wear resistance, long service life and other advantages. Application: Suitable for compact transmission mechanism, high speed and high speed ratio. Such as: cigarette, cigarette machine, papermaking, printing, spinning machinery, HVAC equipment, metal equipment, automatic selling equipment and military industry. After adding anti-static properties, it is also used in the electronics industry substrate line, SMT equipment, circuit board transportation, etc.

Product name Yellow and green substrate
Product type Sheet base band/seamless ring base band/rubber nylon base band/cowhide nylon base band
Substrate surface covered with rubber, cowhide, fiber cloth; Divided into rubber nylon sheet base band and cowhide nylon sheet base band.
Product features wear-resisting, winding resistance, strong tension, long service life.
Product material nylon/rubber/cowhide/industrial fiber cloth
Width range 0mm-500mm(size can be special processing according to customer requirements)
Length range arbitrary length according to customer requirements
Product type yellow-green tablet base band
Product color yellow, green
Connection mode Seamless tape

片基带_01 片基带_02 片基带_03 片基带_04 片基带_05 片基带_06 片基带_07 片基带_08

Other Infomation

High-efficiency double-sided drive belt, it is suitable for high-speed tangential transmission and power transmission in the textile industry, such as rotor spinning machines, twisting machines, drawing machines, fancy bending machines, also often do carding machines, roving machines, marking machines, drawing machines, paper mill and other industries of equipment power belt.

TYPE thickness kind of drive Min. wheel diameter 1% ductility Tension strength Operating temp. Characteristics
(mm) (mm) (N/mm) (N/mm) (℃)
A_001C 1.4 Double-sided transmission 20 2 80 -20~ +100 Anti-static
A_002C 1.5 Double-sided transmission 35 3.5 140 -20~ +100 Anti-static
A_003C 1.7 Double-sided transmission 50 5 200 -20~ +100 Anti-static
A_004C 2 Double-sided transmission 75 7.5 300 -20~ +100 Anti-static
A_005C 2.1 Double-sided transmission 50 5 200 -20~ +100 Anti-static
A_006C 2.3 Double-sided transmission 75 7.5 300 -20~ +100 Anti-static
A_007C 3.2 Double-sided transmission 75 7.5 300 -20~ +100 Anti-static
A_008C 2.4 Double-sided transmission 85 8.5 340 -20~ +100 Anti-static
A_009C 2.4 Double-sided transmission 100 10 400 -20~ +100 Anti-static
A_010C 2.6 Double-sided transmission 100 10 400 -20~ +100 Anti-static
A_011C 3 Double-sided transmission 100 10 400 -20~ +100 Anti-static
A_012C 3.4 Double-sided transmission 100 10 400 -20~ +100 Anti-static
A_013C 2.6 Double-sided transmission 115 11.5 460 -20~ +100 Anti-static
A_014C 2.8 Double-sided transmission 115 11.5 460 -20~ +100 Anti-static
A_015C 3 Double-sided transmission 115 11.5 460 -20~ +100 Anti-static
A_016C 2.6 Double-sided transmission 125 12.5 500 -20~ +100 Anti-static
A_017C 2.8 Double-sided transmission 125 12.5 500 -20~ +100 Anti-static
A_018C 3 Double-sided transmission 125 12.5 500 -20~ +100 Anti-static
A_019C 3.1 Double-sided transmission 150 15 600 -20~ +100 Anti-static
A_020C 3.3 Double-sided transmission 150 15 600 -20~ +100 Anti-static
A_021C 3.9 Double-sided transmission 150 15 600 -20~ +100 Anti-static
A_022C 3.2 Double-sided transmission 175 17.5 700 -20~ +100 Anti-static
A_023C 3.5 Double-sided transmission 175 17.5 700 -20~ +100 Anti-static
A_024C 3.8 Double-sided transmission 175 17.5 700 -20~ +100 Anti-static
A_025C 3.6 Double-sided transmission 200 20 800 -20~ +100 Anti-static

Contact us to get more detail
